High Performance Desert Vehicle (Pure Mechanical Construction)
NRD mid-tube type carThe car adopts a full symmetrical layout with a central driving position; Middle engine power system; All-directional protection anti-roll frame tubular support system; Full restraint seats, full mechanical engine, complete vehicle with extreme electromagnetic defense resistance.
-
Model: NRD mid-tube type carParameter configuration
Drive form: 44
Model: NRD mid-tube type car
Engine: EQB150-20
Chassis model: NRD independent innovation research and development
Emission standard: State III
Engine model: 502Nm mechanical engine
Total weight: 5000KG
Length, width and height: 5100×2200×2050mm
Quality: 3230kg
Body form: steel pipe structure, anti-roll
Transmission: MT
Number of passengers: 5+1, driving in the middle
Front suspension: double fork arm independent suspension
Wheelbase: 3500mm
Rear suspension: double fork arm independent suspension
Wheel base: 1810mm
Brake: disc type with ABS
Drive form: full-time four-wheel drive
Maximum speed: 105km/h
Minimum ground clearance: 400mm
Maximum power: 148Ps
Tire: 305/80R18
Maximum torque: 502Nm
Maximum driving range (km) : 600
Electrical system: 24V, negative pole with iron
Maximum climb: 60%
