High Performance All-Terrain Off-Road Vehicle (Logo Can Be Customized)
NRD2060 SUVUpgrade the chassis structure, greatly improve the crew space, optimize the driving environment. The front axle is double fork arm independent suspension, and the rear axle is a portal leaf spring structure, giving the vehicle strong off-road carrying capacity.
-
Parameter configuration
Drive form: 44
Car model: NRD2060 SUV
Engine: Shangchai π 2.0TT
Chassis model: NRD independent innovation and research and development
Emission standard: State VI
Length, width and height: 4720 2210 1920mm
Total mass: 6,000 KG
Body form: customized body system
Preparation mass: 3,350 kg
Number of occupants: 4 persons
Transmission: ZF 8AT
Wheelbase: 3,300 mm
Front suspension: double fork arm independent suspension
Wheel pitch: 1,810 mm
Rear suspension: leaf-spring door-type bridge
Drive form: intelligent time-sharing drive
Brake: disc type, with ABS
Minimum ground clearance: 400mm
Top speed: 102 km/h
Tire: 305 / 80R18
Maximum power: 217 Ps
Max imum range (km): 600
Maximum torque: 500 Nm
Maximum hill climb degree: 70%
Electrical system: 12V
